产品介绍
Product introduction
产品参数
Product parameters
1. Structure: PET+FILM+GLASS
2. Total thickness of resistance screen: 2.5mm
3. Operating voltage: 3~7V
4. Insulation impedance: ≥ 20M Ω (25V DC)
5. Linearity: ≤ 2.5%
6. Light transmittance: ≥ 78%
7. Operating pressure: 100-120g
8. Service life of resistance screen: ≥ 10000000 times; Stroke life: ≥ 50000 times
9. Working environment: - 10 ° C+50 ° C; Storage environment: - 20 ° C+50 ° C
10. Surface hardness: ≥ 3H (pencil)
